Type 86 fiber optic panel mounting with 2 holes

ODN and passive infrastructure knowledge brief Published 18 May 2025

Prepared for preliminary research by the GESTIONVAL ODN knowledge desk. Confirm network topology, split ratio, box or cabinet capacity, joint closure rating and loss budget against current standards and product documentation.

The Type 86 fiber optic panel with 2 holes is a compact, wall-mountable panel (86x86mm) designed for terminating up to 2 fibers with SC adapters, featuring pre-drilled holes for easy two-screw installation.Key Features
  • Dimensions and Mounting: Standard 86-type size (86x86x25mm) with two pre-drilled mounting holes for secure wall installation, compatible with global 86mm wall boxes and faceplates .
  • Fiber Capacity: Supports up to 2 SC adapters, suitable for single or dual-core fiber connections, making it ideal for FTTH, FTTB, or LAN networks .
  • Material and Protection: Constructed from high-impact ABS plastic, providing waterproof and dustproof protection to safeguard fiber splices and terminations .
  • Internal Design: Includes a fixing plate for organizing fibers, maintaining proper bend radius, and preventing micro-bending or mechanical stress. Some models feature a front and back double-panel design for aesthetic appearance and hidden screw holes .
  • Cable Management: Allows flexible entry/exit for drop cables or indoor soft cables, with internal routing to protect fibers and simplify maintenance .
  • Applications: Suitable for residential, office, and telecom environments, including multi-dwelling units, data centers, and small business premises .
Installation and Use
  • Tool-Free Termination: Many Type 86 panels allow plug-in installation of SC adapters without specialized tools, saving labor time on-site .
  • Compact and Aesthetic: Rounded corners and minimalist design make it suitable for visible wall installations in homes or offices .
  • Maintenance: Removable covers provide easy access to fibers for splicing, testing, or rearrangement . This Type 86 fiber optic panel is a reliable, compact solution for managing fiber connections in small-scale or residential FTTH deployments, offering both protection and ease of installation.
