Huawei Gigabit Optical-to-Electronic Port Module Self-operated

Huawei Gigabit O/E port modules provide reliable 1Gbps connectivity via optical or RJ45 interfaces, supporting various transmission distances and network standards.Overview

Huawei offers a range of Gigabit Ethernet (GE) optical and electrical SFP modules designed for self-operated networks, enabling flexible deployment in switches, routers, and access devices. These modules convert optical signals to electrical signals (and vice versa), supporting high-speed data transmission over fiber or copper cabling.

Key Types and Specifications

1. Electrical (Copper) Modules
   • Model: SFP-GE-T / OEGD01N01
   • Interface: RJ45, 1000BASE-T
   • Transmission Distance: Up to 100 meters over Cat5e/Cat6 cables
   • Features: Auto-negotiation, high compatibility with Huawei switches (S5700, S6700, S9303)
   • Use Case: Short-range connections in corporate networks, data centers, or campus environments
2. Optical Modules
   • Single-mode (SM) Modules: e.g., SFP-GE-LX-SM1310, S-SFP-GE-LH40-SM1310
     • Wavelength: 1310nm
     • Distance: 10–40 km
     • Connector: LC
     • Application: Long-distance fiber links
   • Multi-mode (MM) Modules: e.g., eSFP-GE-SX-MM850
     • Wavelength: 850nm
     • Distance: 0.55 km
     • Connector: LC
     • Application: Short-distance fiber connections within buildings or data centers
   • Bidirectional (BIDI) Modules: e.g., SFP-GE-LX-SM1310-BIDI / SFP-GE-LX-SM1490-BIDI
     • Feature: Single-fiber bidirectional transmission, must be used in pairs
     • Distance: 10 km
     • Application: Reduces fiber usage in point-to-point links

Compatibility and Deployment

Huawei Gigabit O/E modules are tested for compatibility with Huawei switches and optical boards, ensuring reliable link establishment, PING connectivity, and proper operation without anomalies . They are suitable for:

• Enterprise networks requiring flexible uplinks
• Data centers needing high-density, scalable connections
• Campus networks with mixed fiber and copper infrastructure

Additional Features

• Digital Diagnostic Monitoring (DDM): Some optical modules support real-time monitoring of temperature, voltage, and optical power.
• Energy Efficiency: Certain boards and modules support automatic power-off in high-temperature conditions to conserve energy .
• Standards Compliance: Modules comply with 1000BASE-T, 1000BASE-SX, 1000BASE-LX, and other IEEE standards for Gigabit Ethernet.

Summary

Huawei self-operated Gigabit O/E port modules provide versatile, reliable, and standards-compliant solutions for both copper and fiber networks. Electrical modules like SFP-GE-T or OEGD01N01 are ideal for short-range RJ45 connections, while optical modules, including single-mode, multi-mode, and BIDI types, support distances from hundreds of meters to 100 km. Proper selection ensures optimal network performance, compatibility, and efficient fiber utilization .
