Control cables inside cable trays

ODN and passive infrastructure knowledge brief Published 06 Feb 2025

Prepared for preliminary research by the GESTIONVAL ODN knowledge desk. Confirm network topology, split ratio, box or cabinet capacity, joint closure rating and loss budget against current standards and product documentation.

Yes, control cables can be installed in cable trays, provided NEC guidelines for separation, fill, and installation are followed.Compliance and Standards

Control cables are explicitly approved for installation in cable trays under NEC Article 392, which governs cable tray systems . These trays can support power, control, signal, and communication cables, making them suitable for industrial, commercial, and institutional applications . Only tray-rated cables should be used to ensure safety against heat, moisture, and mechanical stress .

Fill Limits

When installing control cables, the tray fill limit is 50% of the tray's cross-sectional area, compared to 40% for power cables . This ensures adequate ventilation and prevents overheating. Proper spacing and secure fastening of cables are essential to maintain integrity and reduce mechanical stress .

Separation and Interference

To minimize electromagnetic interference (EMI), control cables should be separated from high-power cables. Industry practice recommends at least 12 inches (300 mm) vertical or horizontal separation, or the use of metal partitions if space constraints exist . This is particularly important in dense installations or areas with strong electromagnetic fields.

Tray Types and Protection

Control cables can be installed in ventilated, solid-bottom, or wire-mesh trays, depending on environmental conditions and aesthetic requirements . Solid covers or channel trays can provide additional protection for sensitive instrumentation and control cables. In corrosive or outdoor environments, materials like aluminum, steel, or FRP should be selected based on durability and load requirements .

Best Practices
  • Maintain minimum bend radius when routing cables out of trays .
  • Avoid tray locations prone to physical damage; trays should remain accessible for maintenance .
  • Use fire-rated ties in plenum spaces to reduce smoke hazards .
  • Ensure proper grounding and bonding for metallic trays . By following these guidelines, control cables can be safely and efficiently installed in cable trays, ensuring compliance with NEC standards and long-term operational reliability .
